What Are The Basic Commands Of AutoCad?
What Are The Basic Commands Of AutoCad? - Almost all engineering drawing work uses AutoCad. Software released by Autodesk has the flexibility and scalability that can reach anywhere.
Autocad is not the only CAD software used in the industry. However, engineering students are starting to study engineering drawings via AutoCad.
ALSO READ : What Happens If I Reinstall Windows 10
AutoCAD commands
In addition to understanding technical drawings, AutoCAD users have a quick way to draw in no time. The feature is called command.
Command is the column below the screen that functions to enter commands in AutoCAD. One of the benefits of the command line is that it helps you determine the next steps.
Like entering keywords in Google, additional words appear as recommendations. The same is true on the command line.
Every time you enter a command, additional information appears to clarify the command being executed. If you master the command, get ready to be called an AutoCad expert.
ALSO READ : How To Reset Windows 10 Without Losing Data From Boot
List of commands in AutoCAD
In fact, AutoCad is only a tool for drawing. Everything will return to the user.
As a beginner, it is very important to know the AutoCad command line list. Its benefits are very good for work in industry.
About 150 command line lists exist in AutoCad. This number includes commands, keyboard shortcuts and system variables.
You don't have to memorize everything at once. As a starting point, just use the frequently used command. The rest can be followed while studying.
ALSO READ : How To Fix Computer Screen That Is Sideways
List of frequently used autocad commands
Launching from civilmint.com, AnakTeknik will share a list of AutoCad commands that are often used in the industry.
1. Line
This command is used to draw lines either straight or at a certain angle.
To use it, you just need to type L -> press Enter.
2. Retangle
This command can be used to draw a square.
How to use it just type REC -> press Enter.
3. Circles
As the name implies, this command is useful for making circles.
You can enter this command by typing C -> press Enter.
4. Arc
This command is used to create an arc.
The way to enter this command is to type Arc -> press Enter.
5. Copy
The copy command is used to copy objects.
How to use this command is
- Type C/Co or CP in the command field
- Select the object to copy
- Place the copied object in another location, either left or right.
6. Move
Next, the move command to move the object.
Its use can be done by typing M and then pressing enter.
7. Erase
You can use this command to delete objects such as lines, shapes, and more.
How to use it, type E -> press Enter.
8. Rotate
Want to rotate the position without destroying the image, use rotate.
How to use the command by typing RO -> press enter.
9. Mirrors
This command is to make the object's shadow look like a mirror.
How to use it by entering the MI command -> press enter.
10. Thanks
This command is useful for cutting lines that are not needed.
How to use this command by typing TR -> press enter twice.
11. Offsets
This command is useful for making lines parallel.
How to enter this command by typing O -> press enter.
12. Fillets
This command is used to make corner edges soft.
How to use it, namely Type F -> Enter -> specify the fillet radius -> Enter -> select a corner -> Enter.
13. Chamfer
This one command is useful for beveling the edges of corners.
How to use it by typing CHA -> Enter -> specify the length or chamfer angle -> enter -> select both corners -> enter.
14. Hatches
This command is useful for creating different patterns on a selected closed area.
How to use it by typing H -> press enter -> select the pattern used.
15. Extend
Need a longer line? Just use the extend command.
How to use it, type EX -> press enter -> select object -> press enter -> select the line you want to extend to a certain point.
16. PDF import
This command can be used to convert PDF files to CAD.
17. Blocks
The block command is used to create a single geometry group or different geometry types.
How to use it by typing BLOCK -> press Enter -> select an object -> press Enter -> a pop up appears to put the name of the box -> press Enter.
18. Qleader
This feature is used to create two lines with one side arrow. Use fatherly show the direction of the line.
How to use it by typing Qleader -> Press Enter
19. Explodes
This command is to split the block into one object.
How to enter the command by typing X -> press Enter -> select an object -> Press Enter
20. Properties
You can use this command to define geometry characteristics.
How to use this command by typing CH -> press Enter
21. Text
As the name implies, this command is used to write text.
The way to use it is to type TEXT -> press Enter. Next define the height and angle of the text.
22. Dimensions
This command can be used to measure two points. Simply put, this command can bring up the numbers in the picture.
How to use it, type DIM -> select the point you want to measure.
23. Dimangular
The activity of measuring the angle between two points can use the dimangular command.
How to use it by typing DIMANGULAR -> select the first and second point where you want to measure the angle.
24. Scales
Commands to shrink or enlarge an object, you can use scale.
How to use it by typing SC -> Press Enter -> Select object ->. Press Enter -> specify the scale -> Press Enter.
25. Match Properties
The way to assign properties of one object to another object is by using the Match Property command.
The way to use it is to type MA -> Press Enter -> select the specified object -> click another object to set the properties.
